Weld Neck RF Stainless Steel Flange Forged Super Duplex STM A182 F51 F53 F55

Brand Name : Shangle

Model Number : 304/304L,0Cr19Ni10,EN1.4306 ect

Certification : ISO9001 PED

Place of Origin : CHINA

MOQ : Negotiable

Price : Negotiable

Payment Terms : L/C, T/T

Supply Ability : 9999

Delivery Time : 5-7days

Packaging Details : as required

Material : F304L

Type : Slip On

Standard : Ansi Asme

Other : Lap Joint Flange

Application : Natural Gas, Chemical, Power And Metallurgy

Size : 1/2"-24"

Manufacturing Way : Forging;Casting

Packing : Wooden Box

Contact Now

ASTM A182 F51 F53 F55 Super Duplex Steel Forged Weld Neck RF Flange For Water Treatment

Wenzhou Shangle Steel Co., Ltd. (Shangle) founded in 2017,is a comprehensive company integrating industry and trade.As a leading supplier of stainless steel products in Wenzhou, it has a wide range of products in stock that have been rigorously tested and are ready to be shipped.

Din Standard Flanges Description:

Pipe Flanges are widely used as a popular category of pipe fittings. A flange is used to mechanically connect two pipes together. It can also be used to mechanically connect a pipe to a tee, valve, choke or any other piece of equipment. Flanges are available in round, square, and rectangular shapes. In some cases, flanges are usually in the shape of a ring or a plate to form a rim at the end of a pipe when fastened to the pipe. This is an example of closet flange. A flange can also be a plate for covering or closing the end of a pipe. This is a blind flange. Thus, flanges are considered to be projecting or internal components which are used to support mechanical parts. They are like rims which are used to strengthen the mechanical part or they are a means of attaching that part to another part or surface.

DIN 2502 DIN 2503 DIN 2527
DIN 2565 / 2566 DIN 2573 / 2576 DIN 2627 / 2628
DIN 2629 / 2630 DIN 2631 DIN 2632
DIN 2633 DIN 2634 DIN 2635 / 2636
DIN 2637 / 2638 DIN 2641 DIN 2642
DIN 2655 / 2656 DIN 86029 / 86030

Designs of flanges:
A wide variety of flange designs are available. They are available in various shapes and sizes. Some of the popular designs are as follows:

  • Butt weld
  • Socket weld
  • Captive
  • Split
  • Square
  • Round
  • Rectangle etc.

Custom shapes and sizes are also manufactured by numerous manufacturers. Various pipe flanges include machining details such as gasket surfaces, facing details, non-standard drilling, bevel and radius edges, o-ring grooves and raised or recessed faces. Some typical designs on flanges faces are shown below.

Raised Fase Chamfer
Weld Neck RF Stainless Steel Flange Forged Super Duplex STM A182 F51 F53 F55 Weld Neck RF Stainless Steel Flange Forged Super Duplex STM A182 F51 F53 F55
Counter Bore O-Ring Groove
Weld Neck RF Stainless Steel Flange Forged Super Duplex STM A182 F51 F53 F55
Radius Gasket Surface


Applications:
Pipe flanges are widely used in pipe fittings of various industrial, commercial and residential applications. Pipe flanges can be customized to suit your application with various machining details. These pipe flanges have been used extensively in:

  • UHV applications
  • Hydraulic control systems for turbine generators
  • High pressure ground support missile systems
  • Nuclear and conventional power plant applications etc.
Weld Neck RF Stainless Steel Flange Forged Super Duplex STM A182 F51 F53 F55Weld Neck RF Stainless Steel Flange Forged Super Duplex STM A182 F51 F53 F55
